This EPD represents an average product based on data from multiple similar products manufactured Industrias Mar S.A.S. under the TUYCO and GREENTUB brand are ducting systems made from recycled high-density polyethylene (recycled PE). These systems are designed for underground infrastructure applications, such as conduits for telecommunications, electrical, public lighting networks and non pressure wastewater.
Detalle de la información
Información de la Empresa
Documento Download
EPD-IES-0002861:004 (English)Producto que incluye esta EPD
The monotube configuration is available in all standard sizes and pressure classes. HDPE pipes are offered in a wide range of configurations according to Standard Dimension Ratio (SDR), outside diameter, and pressure class. Available SDP values include 26, 21, 17.6, 17, 13.6, 11 and 9, which determine the pipe thickness and corresponding pressure resistance. Pipes are manufactured using PE80 and PE100 resins, with nominal pressures ranging from 5 to 16 kg/cm2 for PE80, and from 6.3 to 20 for PE100, depending on the SDR. Outside diameters range from 16 mm to 225 mm, each associated with a specific wall thickness. Pipes up to 63 mm in diameter are typically supplied in 100 meter coils, while larger diameters are delivered in 12 meter straight lengths.
